Andersen E-Series Specialty Shape Windows
Arches, circles, gothics, trapezoids and dozens more fixed-glass shapes, made to order in any of fifty exterior colors and ten interior woods.
Made in the USA ENERGY STAR® certified Owner-2-Owner® warranty
Overview
Why choose the E-Series Specialty Shape Windows?
When a gable, stairwell or entry calls for something other than a rectangle, E-Series specialty windows deliver it in the exact shape and size you need, from 9" to 144" in either direction. Extruded aluminum-clad wood sashes and frames stand up to the weather while kiln-dried, treated wood interiors take stain or paint, and decorative glass or Finelight™ grilles turn a fixed window into an architectural accent.
Features at a glance
- Extruded aluminum-clad wood sashes and frames
- More than thirty shapes, from equal-leg arches to quatrefoils
- Fifty exterior colors, seven anodized finishes and 2-, 3- and 4-tone combinations
- Select wood components kiln dried and treated with water and insect repellent
- Sizes from 9" to 144" in ⅛" increments
- Owner-2-Owner® limited warranty; Made in the USA; ENERGY STAR® certified
Options
Customize your E-Series Specialty Shape Windows
Every window is built to order. Pick the combination that fits your home and we’ll confirm availability, pricing and lead time at your free consultation.
Exterior colors are factory-finished and warranted against peeling, blistering and fading; interior finishes can be matched to your trim and cabinetry. Ask us for physical samples rather than relying on a screen.
Interior Wood Options (Available Unfinished or Stained)
Factory-Finished Stain Options
Exterior Color
Grilles add architectural character and can be matched to the style of your home. Choose the grille construction first, then the pattern.
Grille Types
Grille Profiles
Interior Wood: Ovolo (Colonial)
Widths: 5/8″ · 7/8″ · 1 1/8″ · 1 1/2″ · 2 1/4″
Available with: Full Divided Light · Simulated Divided Light
Exterior Aluminum: Chamfer
Widths: 5/8″ · 7/8″ · 1 1/8″ · 1 1/2″ · 2 1/4″
Available with: Full Divided Light · Simulated Divided Light · Removable Interior Wood with Optional Permanently Applied Exterior Grille
Removable Interior Wood Grilles
Ovolo or Contemporary profiles in 7/8″ width
Interior Wood: Contemporary
Widths: 5/8″ · 7/8″ · 1 1/8″ · 1 1/2″ · 2 1/4″
Available with: Full Divided Light · Simulated Divided Light
Exterior Aluminum: Contemporary
Widths: 5/8″ · 7/8″ · 1 1/8″ · 1 1/2″ · 2 1/4″
Available with: Full Divided Light · Simulated Divided Light · Removable Interior Wood with Optional Permanently Applied Exterior Grille
Finelight Grille Profiles and Widths
Flat or Contoured profiles in 5/8″ or 1″ widths
Grille patterns
Every Andersen E-Series unit can be ordered with the glass package that fits its exposure. All options are ENERGY STAR® certified configurations; ask us about impact-rated glass for coastal wind zones.
Glass
Decorative and Specialty Glass
Safety GlassTempered safety glass is available on all products, and comes standard on all patio doors.
Laminated GlassLaminated glass is also available, for added strength, enhanced security and sound control.
Sound-Reducing GlassThis glass helps reduce the volume of outside noise. Available with Low-E, SmartSun and HeatLock coatings.
Patterned GlassLet in light while obscuring vision and adding a unique decorative touch to your home.
Stationary specialty windows are built to the exact shape and size of your opening in ⅛" increments — pair them above a double-hung, flank a picture window, or let one stand alone in a gable.
Factory-applied trim completes the look and is often essential for authentic architectural style. Match your window color or choose a contrasting trim.
Interior Trim
Exterior Trim
Blinds and shades applied to the interior of the sash create a triple-glazed window with built-in privacy.
System 3 Blinds & Shades
Add privacy and even greater energy efficiency with this low-maintenance blind or shade solution. Applied to the interior of the sash, the System 3 design creates a triple-glazed window for incredible energy efficiency. Our 5/8″ blinds and pleated shades are mounted to an extruded aluminum storm panel and applied to the interior of the sash. The removable storm panel is available in tan, gold, white, or optional wood-veneer.
Blind Colors
Shade Colors
Control Knobs
Specifications
Product specs
| Brand | Andersen |
|---|---|
| Series | E-Series |
| Window style | Specialty shape (stationary) |
| Exterior Color | 50 Exterior Colors and 7 Anodized Finishes with Custom Color-Match Capabilities |
| 2-, 3-, & 4-Tone Exteriors | Yes |
| Composition | Wood, Aluminum |
| Custom Wood Interiors | Pine, Oak, Walnut, Hickory, Vertical Grain Douglas Fir, Mixed Grain Douglas Fir, Maple, Alder, Mahogany, Cherry |
| Interior Finish | Clear Coat, Autumn Oak, Honey, Russet, Espresso, Birch Bark Basecoat, Wheat, Golden Hickory, Cinnamon, Mocha, White Basecoat, Primed |
| Uniform Sight Lines | Yes |
| Extension Jamb | Pre-installed, dimensional extension jambs available in all wood species. |
| Security Sensors | No |
| Construction Type | Build, Remodel, Replace |
| Custom Sizes | Yes, Available in custom sizes to fit most projects, including replacement. |
| Sizing | Measured in 1/8″ increments. |
| Minimum Width | 9″ |
| Maximum Width | 144″ |
| Minimum Height | 9″ |
|---|---|
| Maximum Height | 144″ |
| Jamb Depth | 3 15/16″ |
| Flange Setback | 1 1/16″ |
| Sash Construction | Weather strip not required since there are no operable parts. |
| Power Operator Available | N/A |
| Energy Star Certification | Yes |
| NFRC Ratings | Yes |
| WDMA Hallmark Certification | Yes |
| AAMA Certification | Yes |
| Glass Warranty | 20 Years |
| Glass Breakage Warranty | No |
| Non-Glass Warranty | 10 Years |
| Labor Warranty | No |
| Window Opening Control Device | N/A |
| Retractable Insect Screen | N/A |
