E-Series awning windows are highly customizable and the perfect choice for high-end homes. These wood windows are energy-efficient and have virtually maintenance-free aluminum exteriors.
Andersen Windows and Doors is America’s premier window manufacturer. The E-Series is one of two lines offered under Andersen’s Architectural Collection.
- Wood interior window frames are protected by the full strength of extruded aluminum cladding
- Wood harvested from managed forests, water-based finishes, and reclaimed aluminum prove devotion to environmentally responsible products
- Owner-2-Owner Limited Warranty Windows Made in the USA
- Select wood components are kiln dried and treated with water/insect repellant and preservative
- Made-to-order in nearly any shape, size, color, interior wood species or finish
Interior Wood Options (Available Unfinished or Stained)
Pine
Maple
Oak
Cherry
Mahogany
Alder
Walnut
Hickory
Vertical Grain Douglas Fir
Mixed Grain Douglas Fir
Custom
Painted Interiors
White
Birch Bark
Primed
Canvas
Sandtone
Terratone
Forest Green
Dark Bronze
Black
Cocoa Bean
Red Rock
Prairie Grass
Dove Gray
Custom
Exterior Color
Hardware Colors
Hardware Styles
Crank Handle & Operator Cover
Antique Brass, Black, Bright Chrome, Oil Rubbed Bronze, Satin Chrome, Pewter, White, Polished Brass, Gold, Bronze
Grille Types
Full Divided Light
Grilles applied to the interior and exterior of the window with aluminum spacers between the glass create an authentic look.
Simulated Divided Light
An economical solution with traditional beauty, Andersen's Simulated Divided Light features fixed exterior and interior grilles without an internal spacer.
Removable Interior Wood Grilles
Andersen's removable wood grilles are installed on the interior surface. They are available with an optional surround and an optional permanently applied exterior grille.
Finelight™ Grilles- Between-the-Glass
Aluminum grilles sit between two panes of glass for easy cleaning.
Grille Profiles
Interior Wood: Ovolo (Colonial)
Widths:
- 5/8″
- 7/8″
- 1 1/8″
- 1 1/2″
- 2 1/4″
Available with:
- Full Divided Light
- Simulated Divided Light
Exterior Aluminum: Chamfer
Widths:
- 5/8″
- 7/8″
- 1 1/8″
- 1 1/2″
- 2 1/4″
Available with:
- Full Divided Light
- Simulated Divided Light
- Removable Interior Wood with Optional Permanently Applied Exterior Grille
Removable Interior Wood Grilles
Ovolo or Contemporary profiles in 7/8″ width
Interior Wood: Contemporary
Widths:
- 5/8″
- 7/8″
- 1 1/8″
- 1 1/2″
- 2 1/4″
Available with:
- Full Divided Light
- Simulated Divided Light
Exterior Aluminum: Contemporary
Widths:
- 5/8″
- 7/8″
- 1 1/8″
- 1 1/2″
- 2 1/4″
Available with:
- Full Divided Light
- Simulated Divided Light
- Removable Interior Wood with Optional Permanently Applied Exterior Grille
Finelight Grille Profiles and Widths
Flat or Contoured profiles in 5/8″ or 1″ widths
Prairie
Diamond
Colonial
Fractional
Victorian
Custom Patterns
Glass
SmartSun™ Glass
SmartSun™ glass gives you the benefits of Low-E glass, plus it helps shield your home from the sun’s heat by filtering out harmful UV rays.
Ideal for: All Climates
SmartSun™ with HeatLock Coating is also available on 100 Series windows. This prevents more heat from escaping your home but slightly reduces the visible light transmitted through the glass.
Low-E/Low-E4® Glass
Low-E Glass reflects heat in the summer and helps to retain interior heat in the winter.
Ideal for: All Climates
Low-E4® with HeatLock Coating is available on A-Series windows. This improves the U-Factor performance of the window but slightly reduces how much light comes through the glass.
Sun Glass
Sun glass has excellent thermal performance. This glass has a subtle tint that blocks out more heat from the sun.
Ideal for: Southern Climates
PassiveSun® Glass
If you live in a cold climate, PassiveSun® glass allows the sun to heat your home.
Ideal for: Northern Climates
Triple-Pane Glass
An extra pane of glass helps keep more heat in and cold air out, making this our most energy-efficient glass option. Perfect for colder climates where more months of the year are spent heating the home.
Ideal for: Northern Climates
HeatLock® Technology
HeatLock® coating reflects heat that likes to escape your home through window glass. It can be added to most of Andersen’s glass options.
Decorative and Specialty Glass
Safety Glass
Tempered safety glass is available on all products, and comes standard on all patio doors.
Laminated Glass
Laminated glass is also available, for added strength, enhanced security and sound control.
Sound-Reducing Glass
This glass helps reduce the volume of outside noise. Available with Low-E, SmartSun and HeatLock coatings.
Patterned Glass
Let in light while obscuring vision and adding a unique decorative touch to your home.
Interior Trim
Wood Casings
A subtle touch around the perfect window or door makes your view even more special.
Shown above, from top to bottom:
½” and 3 ¼” Fluted Casing
11/16″ and 2 ¼” Colonial Casing (WM366)
11/16″ and 2 ¼” Colonial Casing (WM356)
11/16″ and 2 ¼” Ranch Casing (WM324)
Plinth Blocks
Add plinth blocks at the corners for just the right touch of detail.
2 ½” and 3 ½” plinth blocks shown
Exterior Trim
2-, 3- & 4-Tone Exteriors
With our 2-, 3- and 4-tone color combinations, the sky’s the limit. Mix and match up to four of our 50 exterior colors for a combination look that’s all your own.
2” brick mould and 1 ½” sill nose shown on casement.
3 ½” backband & bead casing and 1 ½” sill nose shown on double-hung.
5 ½” flat casing and 1 ½” sill nose shown on casement.
2” ovolo brick mould and 1 ½” deep sill nose shown on double-hung.
3 ½” brick mould and 1 ½” deep sill nose shown on double-hung.
System 3 Blinds & Shades
Add privacy and even greater energy efficiency with this low-maintenance blind or shade solution. Applied to the interior of the sash, the System 3 design creates a triple-glazed window for incredible energy efficiency. Our 5/8″ blinds and pleated shades are mounted to an extruded aluminum storm panel and applied to the interior of the sash. The removable storm panel is available in tan, gold, white, or optional wood-veneer.
Blind Colors
Shade Colors
Control Knobs
As soon as we finished the installation of our Andersen 400 Series we noticed an instant difference in the cooling of our home. Also the outside noise was significantly reduced. My wife and I truly enjoy our new windows.
— MRD57, Review from AndersenWindows.com
Product Specs
| Brand | Andersen |
|---|---|
| Series | E-Series |
| Exterior Color | 50 Exterior Colors and 7 Anodized Finishes with Custom Color-Match Capabilities |
| 2-, 3-, & 4-Tone Exteriors | Yes |
| Composition | Wood, Aluminum |
| Custom Wood Interiors | Pine, Oak, Walnut, Hickory, Vertical Grain Douglas Fir, Mixed Grain Douglas Fir, Maple, Alder, Mahogany, Cherry |
| Interior Finish | Clear Coat, Autumn Oak, Honey, Russet, Espresso, Birch Bark Basecoat, Wheat, Golden Hickory, Cinnamon, Mocha, White Basecoat, Primed |
| Uniform Sight Lines | Yes |
| Extension Jamb | Pre-installed, dimensional extension jambs available in all wood species. |
| Security Sensors | Yes. Verilock sensors are available in five colors. Wireless open/closed sensors are available in four colors. |
| Construction Type | Build, Remodel, Replace |
|---|---|
| Custom Sizes | Yes, Available in custom sizes to fit most projects, including replacement. |
| Sizing | Measured in 1/8″ increments. |
| Minimum Width | 24″ |
| Maximum Width | 48″ |
| Minimum Height | 20″ |
| Maximum Height | 48″ |
| Jamb Depth | 3 15/16″ |
| Flange Setback | 1 1/16″ |
| Sash Construction | A continuous bulb weather strip and secondary bulb weather strip are available in white or black. |
| Power Operator Available | Yes |
| Energy Star Certification | Yes |
|---|---|
| NFRC Ratings | Yes |
| WDMA Hallmark Certification | Yes |
| AAMA Certification | Yes |
| Glass Warranty | 20 Years |
| Glass Breakage Warranty | No |
| Non-Glass Warranty | 10 Years |
| Labor Warranty | No |
| Window Opening Control Device | No |
| Retractable Insect Screen | Yes |
